DMT-FP9000-16-PT
Conventional central 16 areas with LCD screen - 2 Siren output - 2 alarm and fault outputs and 6 configurable relay outputs - Repeater output - Up to 30 detectors per zone - End-of-line resistance auto detection
Description
DMTECH
Conventional fire alarm panel of 16 zones
Certificate EN54-2 and EN54-4
2 independent siren outputs
2 auxiliary alarm and fault outputs
6 configurable relay outputs
Individual output for repeaters
Capacity for 2 12V batteries
4 access levels ((3 user and 1 manufacturer)
LCD display with menu for advanced programming
Specifications
| Primary power supply | Switching source 187-252V AC 50-60 Hz 65W max. |
| Backup power supply | 2 batteries 12VDC (up to 18 Ah). Ensures minimum 72 hours duration. |
| Available languages | Spanish, English, Portuguese, Italian, French, and German. |
| Number of zones | 16 zones, up to 30 detectors by area. |
| Siren outputs | 2 siren outputs 24VDC. Independent and monitored open collector outputs |
| Relay outputs | 8 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max. |
| End of line resistance | Areas fully monitored by end-of-line resistance (4.7K) |
| Auxiliary Output Voltage | 24VDC. Protected by resettable electronic fuse 1.85A |
| Protection Index | IP30 |
| Temperature | -5ºC~+45ºC |
| Material and colour | ABS, colour: White |
| Dimensions | 370 x 410 x 80 mm |
| Weight | 2.5Kg |
| Recommended cable | Fire cable with a minimum section of 1.0mm (18AWG). |
