DS-2DE5232W-AE

Camera
Image Sensor: | 1/2.8" progressive scan CMOS
Minimum Illumination: | Ultra-low light: Color: 0.005 Lux @(F1.6, AGC ON)
                                      B/W: 0.001 Lux @(F1.6, AGC ON)
White Balance: | Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
AGC: | Auto/Manual
BLC: | ON/OFF
HLC: | Support
Smart defog: | Support
WDR: | 120dB
Shutter Time: | 1/1 s to 1/30,000 s
Day& Night: | ICR
Digital Zoom: | 16X
Privacy Masking: | 24 programmable privacy masks
Auto Focus: | Auto/Semi-automatic/Manual
Lens
Focal Length: | 4.8 mm to 153 mm, 32× optical
Zoom Speed: | Approx. 3.5 s (optical lens, wide-tele)
Angle of View: | Horizontal field of view: 55.6° to 2.04° (wide-tele)
                          Vertical field of view: 32.4° to 1.14° (wide-tele)
                          Diagonal field of view: 63° to 2.34° (wide-tele)
Minimum Working Distance: | 10 mm to 1500 mm (wide-tele)
Aperture Range: | F1.6 to F4.6
Pan & Tilt
Pan Range: | 360° endless
Pan Speed: | Configurable, from 0.1°/s to 250°/s
                      Preset Speed: 300°/s
Tilt Range: | From -5° to 90° (Auto-flip)
Tilt Speed: | Tilt Manual Speed: 0.1°-150°/s,
                    Tilt Preset Speed: 200°/s
Number of Preset: | 300
Patrol: | 8 patrols, up to 32 presets per patrol
Pattern: | 4 pattern scans, record time over 10 minutes for each scan
Power loss recovery: | Support
Park Action: | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PTZ Position Display: | ON/OFF
Freeze Frame: | Support
Smart Features
Smart Detection: | Audio Exception Detection, Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection
Smart Tracking: | Manual Tracking, Auto Tracking, Event Tracking
Smart Record: | ANR (Automatic Network Replenishment), Dual-VCA
Alarm
Alarm Input: | 2-ch
Alarm Output: | 1-ch
Input & Output
Audio Input: | 1-ch
Audio Output: | 1-ch
Network
Max.Image Resolution: | 1920×1080
Main Stream: | 50Hz: 25fps (1920×1080, 1280×960, 1280×720)
                                   50fps (1920×1080, 1280×960, 1280×720)
                        60Hz: 30fps (1920×1080, 1280×960, 1280×720)
                                   60fps (1920×1080, 1280×960, 1280×720)
Sub Stream: | 50Hz: 25fps (704×576, 640×480, 352×288)
                       60Hz: 30fps (704×480, 640×480, 352×240)
Third Stream: | 50Hz: 25fps (1920×1080, 1280×960, 1280×720, 704×576, 640×480, 352×288)
                         60Hz: 30fps (1920×1080, 1280×960, 1280×720, 704×480, 640×480, 352×240)
Image Compression: | Main Stream: H.265+/H.265/H.264+/H.264
                                    Sub-Stream: H.265/H.264/MJPEG
                                    Third Stream: H.265/H.264/MJPEG
ROI encoding: | Main stream, sub-stream and third stream respectively support four fixed areas.
Audio Compression: | G.711ulaw/G.711alaw/G.726/MP2L2/G.722/PCM
Protocols: | Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
No. of Simultaneous Users: | Up to 20 users
Dual Stream: | Support
Storage: | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR
User/Host Level: | Up to 32 users,3 Levels: Administrator, Operator and User
Security Measures: | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
EZVIZ: | Support
Client GUI
Camera Control: | Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode
Date & Time Display: | Time: Week: Date, 6 formats on the Client
Client: | Support iVMS-4200
Web Browser: | IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +
General
Menu Language: | English
Power Supply: | 24 VAC & PoE+ (802.3at, class4), Max.:18 W
Working Temperature/Humidity: | -30°C to 65°C (-22°F to 149°F)
                                                     90% or less
Protection Level: | IP66 Standard, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Dimensions: | Φ 220 mm × 280 mm (Φ 8.66" × 11.02")
Weight (approx.): | 3Kg (6.61Ibs)

Nota: Alimentador não incluído.
