DS-2PT3326IZ-DE3

Panoramic Camera
Image Sensor:| Three 1/2.8" progressive scan CMOS
Min. Illumination:| Color: 0.05 Lux @(F2.0, AGC ON)
                             B/W: 0.01 Lux @(F2.0, AGC ON)
                             0 Lux with IR
Shutter Time:| 50Hz: 1/1 s to 1/30,000 s
                       60Hz: 1/1 s to 1/30,000 s
Day & Night:| IR Cut Filter
Gain:| Auto/Manual
WDR:| Digital WDR
Smart Image Enhancement:| HLC/BLC/3D DNR/Defog/Regional Exposure
White Balance:| Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Privacy Mask:| 4 × 3 programmable privacy masks
Focal Length:| 2 mm
Aperture Range:| F2.0
FOV:| Horizontal field of view: 128.5°× 3
          Vertical field of view: 75.7°
          Diagonal field of view: 144°
PTZ Camera
Image Sensor:| 1/2.8" progressive scan CMOS
Min. Illumination:| Color: 0.05 Lux @(F2.0, AGC ON)
                             B/W: 0.01 Lux @(F2.0, AGC ON)
                             0 Lux with IR
Shutter Time:| 50Hz: 1/1 s to 1/30,000 s
                        60Hz: 1/1 s to 1/30,000 s
Day & Night:| IR Cut Filter
Gain:| Auto/Manual
WDR:| Digital WDR
Smart Image Enhancement:| HLC/BLC/3D DNR/Defog/Regional Exposure/Regional Focus
White Balance:| Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent
Lamp/Sodium:| Lamp
Privacy Mask:| 8 programmable privacy masks
Digital Zoom:| 8×
Focus Mode:| Semi-automatic/Manual
Focal Length:| 2.8 mm to 12 mm, 4× optical zoom
Zoom Speed:| Approx.5.4 s (optical, wide - tele)
FOV:| Horizontal field of view: 120° to 56.6° (wide - tele)
          Vertical field of view: 61.8° to 31.7° (wide - tele)
          Diagonal field of view: 149° to 65° (wide - tele)
Min. Working Distance:| 10 mm to 1500 mm (wide - tele)
Aperture Range:| F2.0 to F2.4
Pan and Tilt Range:| Pan: 0°to 350°; Tilt: 0°to 90°
Pan and Tilt Speed:| Pan speed: 0.1°/s to 30°/s (configurable), preset speed: 30°/s
                                  Tilt speed: 0.1°/s to 30°/s (configurable), preset speed: 30°/s
Proportional Zoom:| Support
Preset Number:| 300
Power-off Memory:| Support
PTZ Status Display:| Support
Preset Freezing:| Support
Scheduled Task:| Preset/Dome Reboot/Dome Adjust
Dual-VCA:| Support
Smart Event Detection:| Audio Exception Detection, Intrusion Detection, Line Crossing Detection
System
IR:| Up to 10 m IR (radius)
PTZ Linkage:| Support
SVC:| Support
ROI:| Main stream supports eight fixed areas.
Video Compression:| Main stream: H.265/H.264/MJPEG
                                  H.264: Main Profile/High Profile
Video Bitrate:| 32 Kbps to 8192 Kbps
Audio Compression:| G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2
Audio Bitrate:| G.711alaw/G.711ulaw: 64 Kbps
                        G.711alaw/G.711ulaw: 64 Kbps
                        MP212: 32 Kbps/64 Kbps/128 Kbps
Resolution:| Main stream: 50Hz: 25fps(1920×1080, 1280×720, 704×576, 640×480, 352×288)
                                          60Hz: 30fps(1920×1080, 1280×720, 704×480, 640×480, 352×240)
Basic Event Detection:| Motion Detection, Video Tampering Detection, Exception
Network
Smart Record:| ANR (Automatic Network Replenishment)
Network Storage:| Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
Protocols:| IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
API:| Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party
Management Platform
Simultaneous Live View:| Up to 4 × 4 channels
User/Host:| Up to 32 users.
                   3 levels: Administrator, Operator and User
Security Measures:| User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Client:| iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:| IE 8+, Firefox 30+, Safari 8.0+ web browser
Interface
Network Interface:| 1 RJ45 10 M/100 M Ethernet
Audio Interface:| 1-ch audio input and 1-ch audio output
General
Power:| 12 VDC (Max.24 W), PoE+ (Max. 25 W), IR Max. 6 W
Working Temperature:| -10°C to 50°C (14°F to 122°F)
Working Humidity:| ≤ 90%
Protection Level:| TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
Material:| PC + ABS & Aluminum alloy
Dimensions:| Φ 183 mm × 133.2 mm (Φ 7.20" × 5.24")
Weight:| Approx. 0.9 kg (1.98 lb)

Nota: Alimentador não incluído.
