UV-IPC2225SE-DF40K-WL-I0

5 MP IP Camera - Prime range - 1/2.7" Progressive Scan CMOS - 4.0 mm Lens - White light LEDs - Range 30 m - WEB, CMS, Smartphone and NVR interface

Availability

+ 5 Days

Description

Uniview

Bullet IP camera

Prime range

1/2.7" Progressive Scan CMOS

5 Megapixel 16:9 (2880x1620)

4 mm Lens

White light LEDs for color image 24/7

Range 30 m

WDR 120dB

Intelligent Perimeter Protection | Accurate detection of humans and vehicles (avoids false alarms)

Compression Ultra265/H.265/H.264

Audio

Alarms

PoE IEEE802.3af

Weatherproof IP67

Vandal proof IK10

Surge protection

MicroSD slot

WEB, CMS, Smartphone and NVR interface

ONVIF Compatible

Specifications

Brand	Uniview
Range	Prime
Image sensor	1/2.7" Progressive Scan CMOS
Maximum resolution	5 Megapixel (2880x1620)
Main Stream rate	25 fps (2880 x 1620, 2560 x 1440, 2304 x 1296) 30 fps (1920 x 1080)
Extra Stream rate	2º: 720p (1 ~ 30 FPS), 3º: D1 (1 ~ 25 FPS)
Compression	Ultra265/H.265/H.264
Lens	4 mm
Minimum illumination	0.001 Lux (Colour)
Infrared range	30 m
Image improvements	WDR 120dB, BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
SIP (Smart Intrusion Prevention)	Intelligent Intrusion Prevention. Accurate detection of humans and vehicles to avoid false alarms. Event due to line crossing, area intrusion or entry or exit of a previously defined area
Day / Night	Automatic and configurable
Internal memory	Slot for microSD card up to 256GB
Alarms	1 input / 1 relay
Audio	1 IN / 1 OUT
Network interface	Ethernet 10/100 BaseT
Remote access	Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Interoperability	ONVIF
Power	DC 12 V / 9 W, PoE IEEE802.3af
Temp. operation	-30º C ~ 60º C
Degree of protection	Waterproof IP67, Vandal-proof IK10, Surge protection
Dimensions	85 (H) x 64 (W) x 246 (D) mm
Weight	920 g

Contents

Uniview IP Camera

Installation material

User instructions
