UV-IPC3615LE-ADF28K-G

5 MP IP Camera - Easy range - 1/2.7" Progressive Scan CMOS - 2.8 mm Lens - IR LEDs Range 30 m - WEB, CMS, Smartphone and NVR interface

Availability

+ 5 Days

Description

Uniview

Turret IP Camera

Easy range

1/2.7" Progressive Scan CMOS

5 Megapixel (2880x1620)

2.8 mm Lens

0 Lux

IR Range 30 m

WDR 120dB

Compression Ultra265/H.265/H.264

Integrated microphone

RJ-45 10/100 BaseT

PoE IEEE802.3af

Weatherproof IP67

Surge protection

MicroSD slot

WEB, CMS, Smartphone and NVR interface

ONVIF Compatible

Specifications

Brand	Uniview
Range	Prime
Image sensor	1/2.7” Progressive Scan CMOS
Image resolution	5 Megapixel (2880X1620)
Main stream rate	Main Stream: 5MP (28801620), Max 25fps;4MP (25601440), Max 25fps; 3MP (23041296), Max 30fps; 1080P (19201080), Max 30fps;
Extra stream rate	720P (1280*720), Max 25fps
Compression	Ultra 265, H.265, H.264, MJPEG
Lens	2.8 mm
Minimum illumination	0.003Lux ( F1.6, AGC ON)
Infrared range	30 m
Image improvements	WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
Day/Night	Mechanical ICR filter
Internal memory	MicroSD card, Max 256 GB
Video backup	ANR video recovery technology by installing a Micro SD card
Audio	Integrated microphone
Network interface	Ethernet 10/100 BaseT
Remote access	Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Interoperability	ONVIF
Power	DC 12 V / 6 W, PoE IEEE802.3af
Operating Temp	-30º C ~ 60º C
Degree of protection	Weatherproof IP67
Dimensions	Φ118 x 95mm
Weight	350 g

Contents

Uniview IP Camera

Installation tools

User instructions
